Zebra ZD611-HC Desktop Label Printer (ZD6AH23-T0EE00EZ)

Name: Zebra ZD611-HC Desktop Label Printer (ZD6AH23-T0EE00EZ)
Brand: ZEBRA
SKU: ettzd611hc-6
Availability: OutOfStock

612,24 € +VAT

Product variants

Resolution (dpi)

203300

Print Method

Direct thermalThermal transfer

Series

CutterTear-off

Display

—touch screen

Notify me when in stock

Free Shipping over 250 €. Usually delivered within 3–5 working days.

0% VAT for EU/EEA companies (excl. Estonia). Enter a valid VAT number to automatically generate a 0% VAT invoice.

Available: Out Of Stock
Vendor: ZEBRA
Type: Desktop Printers
Barcode: ZD6AH23-T0EE00EZ
Collections: Desktop Label Printers , Label Printers , Zebra ZD611

📄 Download Product Brochure (PDF)

ZEBRA

Zebra ZD611-HC Desktop Label Printer (ZD6AH23-T0EE00EZ)

612,24 € +VAT

Description

Description

The Zebra ZD611t-HC (ZD6AH23-T0EE00EZ) is Zebra's premium 2-inch thermal transfer desktop label printer for hospitals, laboratories and pharmacies – specimen and prescription labels and patient wristbands. It prints at 300 dpi with a maximum print width of 54 mm and up to 152 mm/s, takes 127 mm label rolls and connects via USB, USB Host and Ethernet. A 4.3-inch colour touch display with wizards makes setup and troubleshooting easy. Disinfectant-ready white plastics, a sealed button interface and an IEC 60601-1 medical power supply make it safe for clinical use. ZPL and EPL support, Link-OS and Zebra Print DNA let it slot straight into existing Zebra fleets.

📦 What's in the box – ZD6AH23-T0EE00EZ

✅ Zebra ZD611t-HC printer – White, colour touch display, USB + Ethernet
✅ Power supply – medical-grade power supply, IEC 60601-1 certified
✅ Power cords (EU + UK) – EU (Schuko) and UK (type G) – both in the box
✅ USB cable – USB A-to-B, ready to connect to your PC
✅ Empty ribbon take-up core – 12.7 mm (0.5 in)
✅ Quick start guide + regulatory guide – drivers, utilities and manuals are a free download from Zebra
❌ Labels – NOT included – choose compatible Zebra labels below
❌ Ribbon – NOT included – 74 m, 12.7 mm core, 33–58 mm wide, ink outside

✅ Ready to print out of the box: power supply, power cords and USB cable are included – just add labels and a ribbon.

💡 Useful extras: the Zebra P1117258-230 dispenser (peeler) kit or the Zebra P1117258-231 cutter kit – both field-installable; the Zebra P1080383-603 battery with the Zebra P1117258-235 battery base for cordless printing on carts; the Zebra P1134555-017C Wi-Fi 6 + Bluetooth 5.3 or Zebra P1112640-017C Wi-Fi 5 + Bluetooth module for wireless printing; the Zebra P1112640-016 RS-232 serial card; the Zebra P1112640-054 adapter kit for 38, 51 and 76 mm label cores; Zebra 105950-035 cleaning pens for the printhead.

Key Features

300 dpi (12 dots/mm) – crisp small text, 2D codes and tiny labels at up to 152 mm/s (6 ips)
Thermal transfer with quick-load 74 m ribbons on a 12.7 mm core and a media dancer for top print quality – also prints on direct thermal labels
Healthcare design – disinfectant-ready, UV-resistant white plastics, sealed buttons and an IEC 60601-1 medical-grade power supply
Media from 15 to 57 mm wide, rolls up to 127 mm in diameter on 12.7 or 25.4 mm cores (38–76 mm with adapters), fanfold via the rear slot
Movable full-width black-mark sensor and multi-position gap sensor – labels, tags, receipt paper and wristbands
Ethernet, USB 2.0 and USB Host as standard; add RS-232 serial or a Wi-Fi + Bluetooth module in the field
ZPL II and EPL 2 compatible – keep your existing label formats; Print DNA emulations for other printer languages
4.3-inch full-colour touch display with menus, wizards and animations, plus Print Touch (NFC) and Bluetooth LE setup with the Zebra Printer Setup app
Field-installable options: dispenser (peeler), cutter, RS-232 serial card, Wi-Fi + Bluetooth module and a battery for cart use
Print DNA with PrintSecure and Printer Profile Manager Enterprise, real-time clock, 512 MB Flash; ENERGY STAR certified

Ideal Applications

Specimen collection and laboratory labels
Prescription and pharmacy labels
Patient ID wristbands
Lab and blood-bank management
Medical asset labelling
Patient records and charts

All ZD611-HC Versions

The highlighted row is the version you are currently viewing.

Part Number	Print Method	Resolution	Media Options
ZD6AH22-D0EE00EZ	Direct thermal	203 dpi	Tear-off	View product
ZD6AH22-D2EE00EZ	Direct thermal	203 dpi	Cutter	View product
ZD6AH23-D0EE00EZ	Direct thermal	300 dpi	Tear-off	View product
ZD6AH22-T0EE00EZ	Thermal transfer	203 dpi	Tear-off	View product
ZD6AH23-T0EE00EZ (this version)	Thermal transfer	300 dpi	Tear-off	Viewing

Technical Specifications

Part Number	ZD6AH23-T0EE00EZ
Model	Zebra ZD611t-HC
Printer Type	2-inch premium healthcare desktop label printer (ZD600 Series)
Print Method	Thermal transfer (also prints on direct thermal media)
Resolution	300 dpi (12 dots/mm)
Print Speed	Up to 152 mm/s (6 in/s)
Max Print Width	54 mm (2.13 in)
Media Width	15–57 mm (0.585–2.25 in)
Label Length	6.35–991 mm (0.25–39 in)
Roll Diameter	Max. 127 mm (5 in) outer diameter
Core Size	12.7 mm (0.5 in) and 25.4 mm (1 in) standard; 38.1, 50.8 and 76.2 mm with optional adapters
Media Thickness	0.06–0.19 mm (max. in tear-off mode)
Media Type	Roll-fed or fanfold; die-cut or continuous labels with or without black mark, tag stock, continuous receipt paper, wristbands
Sensors	Full-width movable reflective / black-mark sensor; multi-position transmissive / gap sensor
Ribbon	74 m (243 ft) ribbon on 12.7 mm (0.5 in) core, 33–58 mm wide, max. 34 mm OD, ink outside; 1:1 ribbon-to-media ratio; media dancer
Interfaces	USB 2.0, USB Host, 10/100 Ethernet (standard); field-installable RS-232 serial card (P1112640-016)
Wireless	Bluetooth Low Energy 5 for setup with the Zebra Printer Setup app only; optional Wi-Fi 6 + Bluetooth 5.3 (P1134555-017C) or Wi-Fi 5 + Bluetooth (P1112640-017C) module
NFC	Print Touch (NFC) tag – tap to pair and open help pages
Memory	512 MB Flash, 256 MB DDR3 SDRAM (64 MB Flash / 8 MB SDRAM user available); real-time clock
Printer Languages	ZPL II, EPL 2, XML, ZBI, PDF Direct; Print DNA printer emulations; Link-OS
Fonts / Character Sets	16 resident expandable ZPL II bitmap fonts, 2 scalable ZPL fonts, 5 EPL2 fonts, native OpenType support, Unicode
Barcodes	1D: Code 11, Code 39, Code 93, Code 128, ISBT-128, UPC-A, UPC-E, EAN-8, EAN-13 (+2/+5), Plessey, Postnet, Standard / Industrial / Interleaved 2-of-5, Logmars, MSI, Codabar, Planet Code; 2D: Codablock, PDF417, Code 49, Data Matrix, MaxiCode, QR Code, MicroPDF, Aztec
Display	4.3-inch full-colour LCD touch display (480 × 272) with 3-button interface
Media Options	Tear-off (standard); field-installable dispenser / peeler (P1117258-230) and cutter (P1117258-231)
Drivers & Software	Print DNA (PrintSecure, Printer Profile Manager Enterprise, Zebra Printer Setup app), ZebraDesigner Essentials (free), Windows drivers
Mobile Printing	Android, iOS, Windows
Power Supply	Auto-detecting 100–240 V AC, 50–60 Hz, IEC 60601-1 certified medical-grade power supply; ENERGY STAR, Efficiency Level VI; optional 2750 mAh battery
Healthcare Features	White healthcare colour scheme; disinfectant-ready, easy-to-clean plastics; sealed button interface; UV-resistant housing
Dimensions (W × D × H)	138.7 × 242.9 × 169.2 mm
Weight	1.63 kg
Color	White
Operating Temperature	4.4 °C to 41 °C
Storage Temperature	−40 °C to 60 °C
Humidity	10–90% non-condensing (operating)
Certifications	IEC 62368-1, EN 55032 Class B, EN 55035, EN 300 328, EN 301 893, FCC Class B, CE; RoHS, REACH
Warranty	24 months (Zebra ZD611 standard warranty)
In the Box	Zebra ZD611t-HC printer (white, 4.3-inch colour touch display, tear-off), IEC 60601-1 medical-grade power supply, EU and UK power cords, USB cable, empty 12.7 mm ribbon take-up core, quick start guide, regulatory guide – labels and ribbon NOT included

The Zebra ZD611t-HC belongs to Zebra's ZD600 Series of premium 2- and 4-inch desktop printers. Matching Zebra labels, ribbons and accessories are listed on this page. Compare other models in our Desktop Label Printers collection or contact our team for volume pricing.
