The Newland NVF260 is a compact corded presentation scanner built for healthcare – above all for tracking surgical instruments in sterile services departments – and for reading direct part marks (DPM) in industry. A new generation of industrial decoding algorithms reads dot-peened and laser-etched DPM codes, even on curved metal surfaces, while the blue diffuse illumination ring prevents glare from shiny metal. The megapixel 1280 × 800 imager decodes codes as small as 3 mm, and the IP64 housing with its medical-grade coating can be disinfected with alcohol-based solutions without damage. This version, NLS-NVF260-20, is the USB kit: it is supplied with a 1.2 m direct USB cable – plug it in and scan, no power supply needed.
📦 What's in the box – NLS-NVF260-20
- ✅ Newland NVF260 presentation scanner – white, compact cylindrical housing (Ø 65 × 100 mm) with medical-grade coating, IP64 – stands directly on the counter or workbench, scan window on top
- ✅ USB cable – direct USB cable, 1.2 m – connects the scanner to a USB port on your PC or workstation; the scanner is powered via USB
- ❌ Power supply – not needed – the scanner is powered via USB
💡 No stand needed – the NVF260 stands on its own with the scan window facing up: simply hold the instrument or item with its code over the window. One USB cable carries both data and power, so set-up takes seconds.
Key Features
- DPM decoding – a new generation of industrial decoding algorithms reads direct part marks such as dot-peened and laser-etched Data Matrix codes, even on curved surfaces like surgical instruments and metal parts.
- Blue diffuse illumination ring – soft, even light avoids reflections from metal surfaces and removes bottlenecks in the scanning process.
- Megapixel high-density imager – the 1280 × 800 CMOS sensor decodes codes as small as 3 mm: 10 mil Data Matrix at 0–25 mm and 15 mil QR Code at 20–30 mm.
- Made for disinfection – the medical-grade coating withstands alcohol-based disinfectants (even 100% alcohol), and the IP64 housing is dust-tight and protected against splashing water.
- Compact and robust – only Ø 65 × 100 mm and 347 g, and it survives 1.2 m drops; fits on crowded instrument packing tables, lab benches and workstations.
- Plug and play – USB interface with power over USB (230 mA typical), beeper and LED feedback; 24-month (2-year) Newland warranty.
Ideal Applications
- Hospital sterile services (CSSD) – tracking and tracing of surgical instruments and instrument sets
- Hospitals and clinics – small Data Matrix codes on medical devices and consumables
- Laboratories – high-density codes on samples and lab equipment
- Manufacturing – DPM codes on metal and plastic parts, tools and components
- Industrial quality control and repair stations – part traceability at the workbench
Technical Specifications
| Part Number | NLS-NVF260-20 |
|---|---|
| Model | Newland NVF260 |
| Scanner Type | Corded presentation (hands-free) 2D area imager for DPM and high-density codes – compact cylindrical housing with the scan window on top |
| Image Sensor | 1280 × 800 CMOS (megapixel); decodes codes as small as 3 mm |
| Illumination | Diffuse blue LED illumination ring (avoids reflections from metal surfaces) |
| Depth of Field | Data Matrix 10 mil: 0–25 mm; QR Code 15 mil: 20–30 mm |
| Field of View | 32.7° horizontal, 20.7° vertical |
| Scan Angles | Roll 360°, pitch 45°, skew 45° |
| Minimum Print Contrast | 25% |
| 1D Symbologies | EAN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN, Code 128, UCC/EAN-128, AIM 128, Code 39, Code 93, Code 11, Codabar, Interleaved 2 of 5, ITF-14, ITF-6, Standard 2 of 5, Matrix 2 of 5, COOP 25, Industrial 2 of 5, Plessey, MSI-Plessey, ISBT 128, Deutsche 14, Deutsche 12 |
| 2D Symbologies | QR Code, Data Matrix – incl. DPM (dot-peened and laser-etched) codes on curved surfaces |
| Host Interface | USB |
| User Indicators | Beeper, LED indicator |
| Mounting | Free-standing on the counter or workbench; scan window on top |
| Housing | Medical-grade coating; can be disinfected with alcohol-based solutions (even 100% alcohol) without damage |
| Color | White |
| Dimensions (W × D × H) | Height 100 mm, diameter 65 mm |
| Weight | 347 g |
| Power | 5 VDC ± 5% via USB; 230 mA operating (typical), 330 mA (max.); 1150 mW (typical) |
| Environmental Sealing | IP64 |
| Drop | 1.2 m |
| Electrostatic Discharge | ±15 kV (air discharge), ±8 kV (direct discharge) |
| Operating Temperature | −20 °C to 60 °C |
| Storage Temperature | −40 °C to 70 °C |
| Humidity | 5–95% RH, non-condensing |
| Certifications | FCC Part 15 Class B, CE EMC Class B, RoHS |
| Warranty | 24 months (2 years) |
| In the Box | NVF260 presentation scanner (white, IP64, medical-grade disinfectant-resistant housing), USB cable (direct, 1.2 m) – USB-powered, no power supply or stand needed |
Need a scanner for retail checkouts or phone screens instead? Compare other hands-free models in our Presentation Barcode Scanners collection, or contact our team for volume pricing and advice on instrument tracking and DPM applications.
