Elo I-Series 2 15.6" Touch Computer, Core i5, 8 GB / 128 GB, Win 10 IoT, Black (E692244)

The Elo I-Series 2 with Intel 15.6" is a compact all-in-one touch computer with a Full HD TouchPro PCAP touchscreen, Intel Celeron or Core processing, Wi-Fi 5 and Bluetooth 5.0. As the generation preceding the I-Series 3 with Intel, it is a proven, cost-effective platform for POS, self-service, kitchen display and back-office tasks and mounts on any 75 mm VESA fixture or Elo stand. Four micro-USB Elo Edge Connect ports on the display edges take Elo's card reader, barcode scanner, fingerprint reader and other peripherals without extra cables. This version, E692244, combines an Intel Core i5-9500TE with 8 GB DDR4 RAM and a 128 GB M.2 SATA SSD and is supplied with Windows 10 IoT Enterprise LTSC (64-bit) preinstalled. It ships with a 100 W USB-C power adapter and EU/US power cords; stands, mounts and peripherals are ordered separately.

Key Features

• Full HD PCAP touchscreen – 15.6" 1920 × 1080 with 10-point TouchPro projected capacitive touch
• Intel Celeron and Core options – Celeron G4900T, Core i3-9100TE or Core i5-9500TE (vPro, Intel AMT); DDR4 expandable to 32 GB on Core i3/i5
• Elo Edge Connect – four micro-USB ports on the display edges for card reader, barcode scanner, fingerprint reader, status light or RFID
• Slim and mountable – 43.8 mm deep, 2.2 kg, 75 mm VESA – fits Elo tabletop, EloPOS, wall, pole and self-service stands
• Connectivity – Wi-Fi 5 (802.11ac), Bluetooth 5.0, Gigabit LAN, USB 3.0 and TPM 2.0
• Serviceable design – upgradable RAM and SSD, Kensington lock, 50,000 h MTBF and a 3-year warranty

Ideal Applications

• Retail and hospitality POS – on the EloPOS or tabletop stand
• Self-service and information kiosks – VESA- or stand-mounted
• Kitchen display – order screens in restaurant kitchens
• Back office – time and attendance, inventory and meeting room management

Technical Specifications

The I-Series 2 with Intel is available with Celeron, Core i3 and Core i5 processors, with or without Windows 10 IoT; for new projects also consider its successor, the I-Series 3 with Intel, with 12th-generation processors and Wi-Fi 6E. Compare all options in our POS PCs collection or contact us for volume pricing.
