TSC TH220 Desktop Label Printer (TH220-A001-1012)

Name: TSC TH220 Desktop Label Printer (TH220-A001-1012)
Brand: TSC
SKU: tscth220t-3
Availability: OutOfStock

440,62 € +VAT

Product variants

Resolution (dpi)

203300

Series

Care label cutter CutterPeeler / dispenserTear-off

Form Factor

2-inch desktop4-inch desktop

Display

3.5" colour touchscreenNone (LED indicators)

Notify me when in stock

Free Shipping over 250 €. Usually delivered within 3–5 working days.

0% VAT for EU/EEA companies (excl. Estonia). Enter a valid VAT number to automatically generate a 0% VAT invoice.

Available: Out Of Stock
Vendor: TSC
Type: Desktop Printers
Barcode: TH220-A001-1012
Collections: Desktop Label Printers , Label Printers

📄 Download Product Brochure (PDF)

TSC

TSC TH220 Desktop Label Printer (TH220-A001-1012)

440,62 € +VAT

Description

Description

The TSC TH220 (TH220-A001-1012) is a compact 2-inch desktop label printer for thermal-transfer and direct-thermal printing at 203 dpi and up to 203 mm/s (8 ips), with a max. print width of 54 mm. This LED version keeps operation simple with status icons and three buttons – ideal when little configuration is needed. It takes 127 mm label rolls and 90 m ribbons (56–58 mm wide), speaks TSPL-EZD with automatic EPL, ZPL and DPL emulation and connects via USB 2.0, RS-232, 10/100 Ethernet and a USB host port. A factory-fitted peel-off module presents each label ready to apply. Supplied with power supply, EU power cord and USB cable – ready to print.

📦 What's in the box – TH220-A001-1012

✅ TSC TH220 label printer – 203 dpi, 2" (54 mm), USB 2.0 + RS-232 + Ethernet + USB host
✅ Peel-off module (factory-fitted) – dispenses each label from the liner, ready to apply
✅ Power supply – external universal power supply, 100–240 V AC → 24 V DC, 60 W
✅ Power cord – EU plug (Schuko)
✅ USB cable – USB 2.0 A-to-B – connect and print straight away
✅ Ribbon take-up core – empty 0.5" paper core for the 90 m ribbon
✅ Drivers & software – Windows driver, TSC Console and labeling software – free download from TSC
✅ Setup guide
❌ Thermal-transfer ribbon – NOT included – needed for thermal-transfer printing only – direct-thermal labels print without a ribbon
❌ Labels – NOT included – order labels to suit your application (see compatible labels below)
❌ Ethernet (LAN) cable – NOT included – use any standard RJ45 patch cable

✅ Ready to print: power supply, power cord and USB cable are in the box – you only need labels (and a ribbon for thermal-transfer printing).

💡 Useful extras: 57 mm ribbons with the ink on the OUTSIDE on a 0.5" core (max. 90 m), e.g. the TSC 8580-PWR (P159004-001); the TSC OP-COM-0002 external roll mount for large rolls on 3" cores; the TSC WF-DH220-2001 Wi-Fi + Bluetooth 5.0 module for wireless printing.

Key Features

Thermal transfer and direct thermal at 203 dpi – up to 203 mm/s (8 ips), max. print width 54 mm
LED status and icon indicators with feed, pause and reprint buttons – no display to configure
90 m ribbons on a 0.5" core (ink outside), 56–58 mm wide
127 mm (5") label rolls on 25.4–38.1 mm cores, media 15–60 mm wide (down to 10 mm with the optional adaptor); fanfold, black-mark and notched media
TSPL-EZD firmware with automatic EPL, ZPL/ZPL II and DPL language switching – existing label templates print unchanged
USB 2.0, RS-232, 10/100 Ethernet and USB host as standard; Wi-Fi 802.11ac + Bluetooth 5.0 or Bluetooth 5.0 modules can be added later
128 MB Flash, 128 MB SDRAM, microSD slot (up to 512 GB) and real-time clock
Remote management via embedded web page, virtual control panel, TSC Console and SOTI Connect; HTTPS, SNMPv3 and 802.1X security
TPH Care printhead diagnostics, ribbon-low warning and tool-free printhead and platen roller replacement
Factory-fitted peel-off module for print-and-apply labelling
Eco design: 100% recyclable packaging and casing made with 30% recycled plastic; 3-year TSC warranty in EMEA

Ideal Applications

Retail – shelf labels, inventory management and weighing-scale labels
Transport and logistics – shipping and receiving labels
Healthcare – specimen, pharmacy and patient-tracking labels
Apparel – hang tags and textile care labels
Food and beverage – product labelling and track and trace

All TH Series Versions

The highlighted row is the version you are currently viewing.

Part Number	Model	Print Width	Resolution	Display	Media Option
TH220-A001-0002	TH220T	2" (54 mm)	203 dpi	3.5" touch LCD	Tear-off	View product
TH220-A001-1002	TH220	2" (54 mm)	203 dpi	LED (no display)	Tear-off	View product
TH220-A001-1012 (this version)	TH220	2" (54 mm)	203 dpi	LED (no display)	Peeler	Viewing
TH220-A001-1022	TH220	2" (54 mm)	203 dpi	LED (no display)	Cutter	View product
TH220-A001-1032	TH220	2" (54 mm)	203 dpi	LED (no display)	Care label cutter	View product
TH320-A001-0002	TH320T	2" (56.9 mm)	300 dpi	3.5" touch LCD	Tear-off	View product
TH320-A001-1002	TH320	2" (56.9 mm)	300 dpi	LED (no display)	Tear-off	View product
TH320-A001-1012	TH320	2" (56.9 mm)	300 dpi	LED (no display)	Peeler	View product
TH320-A001-1022	TH320	2" (56.9 mm)	300 dpi	LED (no display)	Cutter	View product
TH320-A001-1032	TH320	2" (56.9 mm)	300 dpi	LED (no display)	Care label cutter	View product
TH240-A001-0002	TH240T	4" (108 mm)	203 dpi	3.5" touch LCD	Tear-off	View product
TH240-A001-1002	TH240	4" (108 mm)	203 dpi	LED (no display)	Tear-off	View product
TH340-A001-0002	TH340T	4" (105.7 mm)	300 dpi	3.5" touch LCD	Tear-off	View product
TH340-A001-1002	TH340	4" (105.7 mm)	300 dpi	LED (no display)	Tear-off	View product

Technical Specifications

Part Number	TH220-A001-1012
Model	TSC TH220 (TH Series 2-inch)
Printer Type	2-inch desktop thermal transfer label printer
Print Method	Thermal transfer and direct thermal
Resolution	203 dpi (8 dots/mm)
Print Speed	Up to 203 mm/s (8 ips)
Max Print Width	54 mm (2.13")
Max Print Length	25,400 mm (1,000")
Media Width	15–60 mm (0.59"–2.36"); 10 mm with the optional narrow media adaptor
Media Thickness	0.06–0.19 mm (2.36–7.48 mil)
Roll Diameter	127 mm (5") OD
Core Size	25.4–38.1 mm (1"–1.5")
Media Types	Continuous, die-cut, black mark, fanfold, notched (outside wound); label length 5 mm – 25,400 mm
Sensors	Transmissive gap sensor, reflective black-mark sensor (position adjustable), ribbon-end sensor, head-open sensor
Ribbon	90 m on 0.5" (12.7 mm) core, max. OD 37 mm; width 56–58 mm; ink coated OUTSIDE
Interfaces	USB 2.0, RS-232 serial, internal Ethernet 10/100 Mbps, USB host; microSD card slot
Wireless	None as standard – optional Wi-Fi 802.11a/b/g/n/ac + Bluetooth 5.0 combo module or Bluetooth 5.0 module
Processor	32-bit RISC CPU
Memory	128 MB Flash, 128 MB SDRAM; microSD expansion up to 512 GB (FAT32/exFAT)
Real-Time Clock	Standard
Printer Languages	TSPL-EZD with automatic EPL, ZPL, ZPL II and DPL language switching
Fonts / Character Sets	8 alphanumeric bitmap fonts; Monotype true-type engine with CG Triumvirate Bold Condensed; ARIALUNI.TTF Unicode font (UTF-8); 0/90/180/270° rotation
Barcodes	1D: Code 39, Code 93, Code 128 (UCC, subsets A/B/C), Codabar, Interleaved 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, EAN/UPC add-on, MSI, Plessey, Postnet, China Post, ITF-14, EAN-14, Code 11, Telepen, Planet, Code 49, Deutsche Post Identcode/Leitcode, LOGMARS; 2D: TLC39, Codablock F, PDF417, MicroPDF417, MaxiCode, DataMatrix, QR Code, Aztec, GS1 DataBar
Display	No display – LED status and icon indicators; power, feed, pause and reprint buttons
Media Options	Peel-off module (factory-fitted)
Options	Peel-off module, guillotine cutter, care label cutter, Wi-Fi + Bluetooth 5.0 combo module, Bluetooth 5.0 module, external label roll mount, KP-200 Plus keyboard, 10 mm narrow media adaptor
Management & Security	Internal embedded web page, virtual control panel, TSC Console, SOTI Connect (licence); HTTPS, SNMPv3, 802.1X, TCP/IP port 9100 filter; TPH Care printhead diagnostics
Power Supply	External universal switching power supply: 100–240 V AC, 1.5 A, 50–60 Hz input; 24 V DC, 2.5 A, 60 W output
Dimensions (W × D × H)	146 × 231 × 179 mm (W × D × H)
Weight	1.8 kg
Color	Black
Operating Temperature	0–40 °C, 25–85% RH non-condensing
Storage Temperature	−40–60 °C, 10–90% RH non-condensing
Certifications	CB, FCC Class B, IC, cTÜVus, NOM, CE Class B, UKCA, EAC, CCC, RCM, BSMI, ENERGY STAR 3.0; RoHS, REACH, WEEE
Warranty	Printer: 3 years (TSC EMEA, purchases from 1 June 2024); printhead 25 km or 12 months, platen 50 km or 12 months (whichever comes first)
In the Box	TSC TH220 printer (203 dpi, LED indicators, no display, USB 2.0 + RS-232 + Ethernet + USB host, factory-fitted peel-off module), external power supply (24 V DC, 60 W), power cord (EU Schuko plug), USB cable, empty 0.5" ribbon paper core, quick start guide – ribbon and labels NOT included

Need a different width, resolution, display or media option? All TH Series versions are listed above. Compare other models in our Desktop Label Printers collection or contact our team for volume pricing.
