| Tuotekoodi | XT5-40NS |
| Malli | BIXOLON XT5-40 (XT5-40 series) |
| Tulostintyyppi | 4-inch industrial thermal transfer label printer |
| Tulostustapa | Thermal transfer and direct thermal |
| Tarkkuus | 203 dpi (8 dots/mm) |
| Tulostusnopeus | Up to 356 mm/s (14 ips) |
| Suurin tulostusleveys | 104 mm |
| Tarran pituus | Up to 4,000 mm |
| Materiaalin leveys | 25–114 mm |
| Rullan halkaisija | Max. 203 mm |
| Hylsyn halkaisija | 38.1–76.2 mm (25.4 mm with the optional 1" core media supply hanger) |
| Materiaalin paksuus | 0.06–0.30 mm |
| Materiaalityyppi | Labels with gap, black mark or notch, continuous media, fanfold; thermal transfer and direct thermal |
| Anturit | Transmissive (gap, adjustable), reflective (black mark, adjustable), ribbon end, head open |
| Värinauha | Wax, wax/resin, resin – ink side outside or inside; width 50–110 mm; length up to 450 m; core 25.4 mm (1") |
| Materiaalin käsittelyvaihtoehdot | Tear-off – factory options across the series: peeler, auto-cutter, rewinder + peeler; optional 1" core media supply hanger |
| Liitännät | USB 2.0 (Type B), RS-232 (DB9), Gigabit Ethernet 10/100/1000 Mbps, 2 × USB host |
| Langaton yhteys | Not fitted in this version (WLAN / Bluetooth versions are separate part numbers) |
| Tulostinkielet | SLCS™, BPL-Z™ (ZPL II compatible), BPL-E™ (EPL compatible), BPL-D™ (DPL compatible) |
| Fontit / merkistöt | Bitmap fonts: 10 SLCS™, 16 BPL-Z™, 5 BPL-E™, 9 BPL-D™; scalable fonts: 1 SLCS™, 1 BPL-Z™, 1 BPL-D™; 23 code pages; Unicode (UTF-8, UTF-16LE/BE); user-defined fonts, graphics, formats and logos |
| Viivakoodit | 1D: Codabar, Code 11, Code 39, Code 93, Code 128, EAN-8, EAN-13, Industrial 2 of 5, Interleaved 2 of 5, Logmars, MSI, Plessey, Postnet, GS1 DataBar, Standard 2 of 5, UPC-A, UPC-E, UPC/EAN extensions, IMB; 2D: Aztec, Codablock, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR Code, TLC 39 |
| Muisti | 512 MB SDRAM, 512 MB Flash |
| Näyttö | 4.3" full-colour touch LCD |
| Reaaliaikakello | Yes (standard) |
| Ajurit ja ohjelmistot | Windows driver (Europlus / Seagull), Linux / Mac CUPS driver, Virtual COM USB / Ethernet driver, OPOS / JPOS, SAP® device driver, Label Artist-II™, BarTender® UltraLite for BIXOLON, Network Auto Installer; SDKs for Android, iOS, Windows, Linux, Chrome, Xamarin, Web Print |
| Laitehallinta | BIXOLON Profile Manager XPM™ / XCM™ (Windows, Android), Twin function™ (copy settings and data via USB memory), SoftAP on WLAN versions |
| Mobiilitulostus | Label Artist™ Mobile and mPrint apps (Android, iOS) |
| Virransyöttö | Built-in power supply, 100–120 / 200–240 V AC, 50/60 Hz (24 V DC, 7.5 A) |
| Runko | Aluminium body, adhesive-free metal case, double-folding door with window |
| Mitat (L × S × K) | 269 × 490 × 324 mm |
| Paino | 13.98 kg |
| Väri | Black |
| Käyttölämpötila | 5 °C to 40 °C |
| Säilytyslämpötila | −20 °C to 60 °C |
| Kosteus | Operating 10–80% RH, storage 10–90% RH |
| Takuu | 24 months |
| Pakkauksen sisältö | BIXOLON XT5-40 printer (203 dpi, 4.3" full-colour touch LCD, tear-off, USB, RS-232, Gigabit Ethernet, 2× USB host), built-in power supply, power cord (EU plug, C13), empty ribbon core, quick installation guide – USB cable, serial cable, labels and ribbon NOT included |
