| Tuotekoodi | TH240R-A001-0022 |
| Malli | TSC TH240R (TH Series 4-inch, UHF RFID) |
| Tulostintyyppi | 4-inch desktop thermal transfer UHF RFID label printer / encoder |
| Tulostustapa | Thermal transfer and direct thermal |
| Tarkkuus | 203 dpi (8 dots/mm) |
| Tulostusnopeus | Up to 203 mm/s (8 ips) |
| Suurin tulostusleveys | 108 mm (4.25") |
| Suurin tulostuspituus | 25,400 mm (1,000") |
| Materiaalin leveys | 15–120 mm (0.59"–4.72"); 10 mm with the optional narrow media adaptor |
| Materiaalin paksuus | 0.06–0.19 mm (2.36–7.48 mil) |
| Rullan halkaisija | 127 mm (5") OD |
| Hylsyn koko | 25.4–38.1 mm (1"–1.5") |
| Materiaalityypit | Continuous, die-cut, black mark, fanfold, notched (outside wound); label length 5 mm – 25,400 mm; UHF RFID labels and tags (RAIN inlays) |
| Anturit | Transmissive gap sensor, reflective black-mark sensor (position adjustable), ribbon-end sensor, head-open sensor |
| Värinauha | 300 m on 1" (25.4 mm) core, max. OD 67 mm; or 110 m on 0.5" (12.7 mm) core, max. OD 40 mm; width 40–110 mm; ink coated OUTSIDE |
| Liitännät | USB 2.0, RS-232 serial, internal Ethernet 10/100 Mbps, USB host; microSD card slot |
| Langaton yhteys | None as standard – optional Wi-Fi 802.11a/b/g/n/ac + Bluetooth 5.0 combo module or Bluetooth 5.0 module |
| RFID | Integrated UHF RFID reader/encoder: RAIN RFID (passive UHF), GS1 EPC Gen2 / ISO 18000-63; Encode During Print; RFID auto-calibration (feeds 3 labels to set encoding position and power); TSC Console Web: calibration, read, write; wide range of UHF inlays incl. selected on-metal labels; EMEA unit (EU plug) for the EU UHF band 865–868 MHz |
| Suoritin | 32-bit RISC CPU |
| Muisti | 128 MB Flash, 128 MB SDRAM; microSD expansion up to 512 GB (FAT32/exFAT) |
| Reaaliaikakello | Standard |
| Tulostinkielet | TSPL-EZD with automatic EPL, ZPL, ZPL II and DPL language switching |
| Fontit / merkistöt | 8 alphanumeric bitmap fonts; Monotype true-type engine with CG Triumvirate Bold Condensed; ARIALUNI.TTF Unicode font (UTF-8); 0/90/180/270° rotation |
| Viivakoodit | 1D: Code 39, Code 93, Code 128 (UCC, subsets A/B/C), Codabar, Interleaved 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, EAN/UPC add-on, MSI, Plessey, Postnet, China Post, ITF-14, EAN-14, Code 11, Telepen, Planet, Code 49, Deutsche Post Identcode/Leitcode, LOGMARS; 2D: TLC39, Codablock F, PDF417, MicroPDF417, MaxiCode, DataMatrix, QR Code, Aztec, GS1 DataBar |
| Näyttö | 3.5" colour touch display (480 × 320 px); power, feed, pause and reprint buttons |
| Materiaalin käsittely | Guillotine cutter, full and partial cut (factory-fitted) |
| Lisävarusteet | Peel-off module, guillotine cutter, care label cutter, Wi-Fi + Bluetooth 5.0 combo module, Bluetooth 5.0 module, external label roll mount, KP-200 Plus keyboard, 10 mm narrow media adaptor |
| Hallinta ja tietoturva | Internal embedded web page, virtual control panel, TSC Console, SOTI Connect (licence); HTTPS, SNMPv3, 802.1X, TCP/IP port 9100 filter; TPH Care printhead diagnostics |
| Virransyöttö | External universal switching power supply: 100–240 V AC, 2.0 A, 50–60 Hz input; 24 V DC, 3.75 A, 90 W output |
| Mitat (L × S × K) | 223 × 286 × 186 mm (W × D × H) |
| Paino | approx. 2.8 kg (TH240T base printer, TSC datasheet) |
| Väri | Black |
| Käyttölämpötila | 0–40 °C, 25–85% RH non-condensing |
| Säilytyslämpötila | −40–60 °C, 10–90% RH non-condensing |
| Sertifioinnit | CB, FCC Class B, IC, cTÜVus, NOM, CE Class B, UKCA, EAC, CCC, RCM, BSMI, BIS, KC, ENERGY STAR 3.0; RoHS, REACH, WEEE (TH Series base printer) |
| Takuu | Printer: 3 years (TSC EMEA, purchases from 1 June 2024); printhead 25 km or 12 months, platen 50 km or 12 months (whichever comes first) |
| Pakkauksen sisältö | TSC TH240R printer (203 dpi, 3.5" colour touch LCD, built-in UHF RFID encoder, USB 2.0 + RS-232 + Ethernet + USB host, factory-fitted guillotine cutter), external power supply (24 V DC, 90 W), power cord (EU Schuko plug), USB cable, 2 × 1" ribbon spindles (300 m ribbons), empty 1" ribbon paper core, media adaptor for 120 mm media, quick start guide – ribbon and RFID labels NOT included |
