| Part Number |
SLP-TX420G/BEG |
| Model |
BIXOLON SLP-TX420 (SLP-TX420 Series) |
| Printer Type |
4-inch desktop thermal transfer label printer |
| Print Method |
Thermal transfer and direct thermal |
| Resolution |
203 dpi (8 dots/mm) |
| Print Speed |
Up to 178 mm/s (7 ips) |
| Max Print Width |
108 mm (4.25") |
| Max Print Length |
2,000 mm (78.7") |
| Media Width |
20–110 mm (0.79"–4.33"), incl. liner |
| Media Thickness |
0.06–0.20 mm |
| Roll Diameter |
Up to 130 mm (5.1") OD |
| Core Size |
25.4–38.1 mm (1"–1.5") |
| Media Types |
Gap (die-cut), black mark, notch, continuous, fanfold |
| Sensors |
Transmissive gap sensor, reflective black-mark sensor (adjustable), ribbon-end sensor, head-open sensor; Smart Media Detection™ |
| Ribbon |
Wax, wax/resin, resin; ink OUTSIDE; up to 110 mm wide; up to 74 m on 0.5" (12.7 mm) core |
| Interfaces |
USB (Type B), RS-232 serial, IEEE 1284 parallel |
| Wireless |
None |
| Memory |
64 MB SDRAM, 128 MB Flash |
| Real-Time Clock |
Supported |
| Printer Languages |
SLCS™, BPL-Z™ (ZPL II compatible), BPL-E™ (EPL compatible) |
| Fonts / Character Sets |
Bitmap fonts (10 SLCS, 16 BPL-Z, 5 BPL-E), scalable fonts (1 SLCS, 1 BPL-Z), 23 code pages, Unicode (UTF-8, UTF-16LE/BE) |
| Barcodes |
1D: Codabar, Code 11, Code 39, Code 93, Code 128, EAN-8/13, Industrial/Interleaved/Standard 2 of 5, LOGMARS, MSI, Plessey, Postnet, GS1 DataBar, UPC-A/E, UPC/EAN extensions, IMB; 2D: Aztec, Codablock, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR Code, TLC 39 |
| Display |
No LCD – status LEDs and function keys |
| Media Options |
Tear-off (standard); auto cutter and peeler (optional) |
| Options |
Auto cutter, peeler, external paper supply |
| Drivers & Software |
Windows driver (Europlus / Seagull), Linux/Mac CUPS, virtual COM USB/Ethernet, utility program, OPOS/JPOS driver, BarTender® UltraLite for BIXOLON, Label Artist™-II; Android/iOS/Windows/Linux/Chrome/Xamarin SDKs; Label Artist™ Mobile, mPrint; XPM™/XCM™ device management |
| Power Supply |
External AC/DC power adapter, 100–240 V AC, 50/60 Hz; ENERGY STAR® certified |
| Dimensions (W × D × H) |
200 × 252 × 173 mm |
| Weight |
2.35 kg |
| Color |
Dark grey |
| Operating Temperature |
5–40 °C |
| Storage Temperature |
−20–60 °C |
| Humidity |
Operating 10–80% RH, storage 10–90% RH (non-condensing) |
| Warranty |
36 months |
| In the Box |
BIXOLON SLP-TX420 printer (203 dpi, USB, RS-232, Parallel), external AC/DC power adapter (100–240 V AC), power cord (EU plug), empty 0.5" ribbon core, user's manual; drivers and Label Artist-II / BarTender UltraLite software as free download – USB/interface cable, labels and ribbon NOT included (order separately) |
